SC(B)11 6.3kv 6.6kv Dry Type Transformer Product Overview and Features
Product Overview
The 6.3kV 6.6kV cast resin transformer applies epoxy resin to fully embed both the primary and secondary windings, protecting them from moisture, dust, corrosion, and other conditions that could reduce insulation performance. Cast resin dry type transformers perform reliably in high-humidity zones, indoor environments, and locations with strict fire safety requirements. Their non-hygroscopic and non-flammable design, combined with low losses and tolerance to partial discharges and overloads, contributes to long-lasting efficiency.
Gnee cast resin transformers are typically installed in medium voltage networks across various applications, including factory utilities, substations, industrial operations, schools, commercial buildings, and residential energy systems.
Technical Data
Overall and mounting dimensions(mm)
.png)
Product Advantage
• Compact and Simple Structure
The transformer adopts a compact overall layout and streamlined structural design, effectively reducing the footprint required for installation. Its simple configuration not only makes setup more convenient but also minimizes routine maintenance needs, helping users save time and installation costs.
• Excellent Electrical Performance
With optimized electromagnetic design, the transformer ensures high efficiency and stable operation. It achieves low loss, reduced noise levels, and a controlled temperature rise, maintaining steady performance even under long-term load conditions. These features help improve energy utilization and prolong service life.
• High Safety and Reliability
Utilizing a dry insulation design, the transformer provides a high level of electrical isolation, ensuring dependable performance in demanding environments. It demonstrates strong resistance to short-circuit stress, overload conditions, and lightning impacts, significantly enhancing operational safety and reducing potential downtime.
• Eco-friendly and Sustainable
Since the transformer does not rely on oil as an insulating medium, it eliminates risks associated with oil leakage and avoids contamination of soil and groundwater. This environmentally friendly design supports sustainable operation while reducing the need for pollutive materials.
Applications
The 6.3kv 6.6kv Cast Resin Transformers are engineered for broad use across multiple industries and operating environments. They are widely applied throughout the power sector, including power generation facilities, transmission lines, distribution networks, and substation systems. In chemical engineering, they serve reliably in refineries and pharmaceutical production sites. The transportation industry also deploys them in airports, railway and subway stations, expressways, and tunnel infrastructures.
These transformers are suitable for educational institutions such as schools and training facilities, as well as public service buildings, including administration centers, courts, police and fire stations, embassies, and broadcast stations. They also support various commercial environments, from shopping malls and hotels to banks and exhibition centers.
In the industrial field, they are used in glass factories, cement plants, cold storage facilities, construction projects, agriculture, and food & beverage production. They are also essential in energy exploitation, covering mining, oil, gas, and offshore drilling operations. For renewable energy systems, they integrate seamlessly with solar, wind, and hydropower installations.
Additionally, the transformers are suitable for marine applications such as ports, drydocks, and shipyards, and are commonly used in military & defense, aviation, medical & healthcare facilities, including hospitals and rehabilitation centers. The information & communications sector also relies on them for server rooms, data centers, and base stations.
Carry
Packaging and transportation
F＆Q
1. How can you support us as a partner?
We will offer you the best price, best service and other supporting documents such as quotation, technical data sheet, drawing, reference list, manufacturing plan, quality control plan, testing plan, test report, etc.
2. What is the scope of your after-sale service?
Installation, commissioning, training, maintenance, etc.
3. Why choose Gnee?
Experienced transformer supplier with a professional engineering team.
Complete customer service from quoting to operating.
Quick response 24/7.
About Us
GNEE Electrical Equipment Co., Ltd. was established in 2008 and is located in Anyang City, Henan Province. It is a digital management enterprise integrating power equipment research and development, production, sales and installation. It has more than 200 employees and more than 160 cooperative countries. The company's products cover 6kv, 11kv, 22kv, 35kv, rated capacity 50kva to 5000kva and other power transformers, dry-type transformers, oil-immersed transformers, distribution transformers, box-type substations, and wind power and photovoltaic power generation equipment.
With years of accumulation in the transformer industry and strong technological innovation capabilities, it provides comprehensive solutions for the international power industry.Welcome to your inquiry!
