SC(B)11 10kv Dry Type Transformer Product Overview and Features
Product Overview
Dry-type transformers are available in open type, closed type, and cast type designs, enabling them to meet the requirements of different installation conditions. In cast-type structures, the winding is insulated with epoxy resin or similar materials, while in closed-type configurations, the winding is placed inside a sealed housing that is separated from the outside air—an arrangement commonly used in mining equipment, where heat dissipation is limited but explosion-proof performance is essential. Built with cold-rolled silicon steel sheets and epoxy resin, these transformers offer strong mechanical strength and reliable insulation. Additionally, they incorporate an intelligent temperature monitoring and protection system capable of tracking the real-time temperature of the three-phase winding, controlling the fan’s automatic operation, and issuing warnings or tripping actions when abnormal conditions occur.
Technical Data
Overall and mounting dimensions(mm)
.png)
Product Advantage
High Insulation Strength: Ensures excellent dielectric performance and operational safety.
Strong Short-Circuit Resistance: Engineered to withstand high electrical and mechanical stress.
Exceptional Disaster Prevention: Offers enhanced protection against fire, moisture, and external hazards.
Excellent Environmental Adaptability: Performs reliably under varying environmental conditions.
Low Loss, High Efficiency: Designed to minimize energy loss and improve overall performance.
Compact and Lightweight: Optimized structure for easy installation and space efficiency.
Low Noise: Quiet operation suitable for residential and commercial environments.
Product Features
Epoxy resin cast dry-type transformers use epoxy resin as a non-flammable, flame-retardant, and self-extinguishing solid insulation medium. Because they operate without oil, they offer clean performance, strong short-circuit capability, low losses, compact size, and quiet operation. These transformers are widely applied in scenarios requiring strict fire and explosion protection. Key advantages include:
Safe and eco-friendly — oil-free, fire-resistant, pollution-free design suitable for direct installation at the load center.
High durability — excellent mechanical strength, strong resistance to short-circuit stress, minimal partial discharge, reliable thermal stability, long service life.
Energy-efficient — low loss and low noise, notable energy-saving performance, maintenance-free operation.
Efficient cooling — good heat dissipation and strong overload capacity; forced air cooling can boost operating capacity.
Moisture tolerance — excellent moisture resistance, capable of working in high humidity and harsh environments.
Smart temperature control — equipped with an intelligent signal temperature monitoring system to track three-phase winding temperatures, control fan operation automatically, and provide alarm and trip functions.
Compact structure — small footprint, lightweight design, reduced installation space and cost.
Carry
Packaging and transportation
F＆Q
1. How can you support us as a partner?
We will offer you the best price, best service and other supporting documents such as quotation, technical data sheet, drawing, reference list, manufacturing plan, quality control plan, testing plan, test report, etc.
2. What is the scope of your after-sale service?
Installation, commissioning, training, maintenance, etc.
3. Why choose Gnee?
Experienced transformer supplier with a professional engineering team.
Complete customer service from quoting to operating.
Quick response 24/7.
