Cold Rolled Non-oriented Low Carbon Electrical Steel

26 Mar 2024
Reading Volume :

Non-oriented electrical steel is mainly used as the iron core of large and medium-sized motors, generators, household motors and micro-motors, ballasts and small transformers. The main magnetic performance requirements of non-oriented electrical steel are low specific total loss and high magnetic polarization. The low specific total loss can save a lot of electric energy and extend the working time of the motor. High magnetic polarization means that the magnetization ability is strong, the excitation current of the iron core is reduced, and the specific total loss and iron loss are reduced.


Product Parameters

Category

Silicon Content/%

Nominal Thickness/Mm

Lord To Use Way

Hot Rolled Silicon Steel

(No Orientation)

Hot rolled low silicon steel(Motor Steel)

1.0~2.5

0.5

Household motors and micromotors

Hot rolled high silicon steel(Transformer steel)

3.0~4.5

0.35,0.50

Transformer

Cold Rolled Electrical Steel

Cold rolled non-oriented electrical steel(Motor Steel)

Low carbon electrical steel

≤ 0.5

0.50,0.65

Small transformers and ballasts for household motors, micromotors

Silicon steel

>0.5~3.5

0.35,0.50

Medium and large motors, generators and transformers

Cold rolled grain oriented silicon steel(Transformer steel)

Ordinary oriented silicon steel

2.9~3.3

0.18,0.23,0.27
0.30,0.35

Large, medium and small transformers and ballasts

High magnetic induction oriented silicon steel

Special Purpose Silicon Steel

Cold rolled grain oriented silicon steel strip

2.9~3.3

0.03,0.05,0.10

Pulse transformer, magnetic amplifier, high frequency transformer and electric welding machine

Cold rolled non-oriented silicon steel strip

3.0

0.15,0.20

High-frequency motors and generators

Cold rolled non-oriented silicon steel for magnetic switch

3.0

0.70

Relays and magnetic switches

Cold rolled high silicon steel

6.5

0.1~0.5

High-frequency motors, transformers and magnetic shielding

Cold rolled Grain Non oriented silicon steel
Grain Non oriented electrical steel
