In the modern industrial landscape, energy efficiency is no longer an option—it is a competitive necessity. As a leading professional transformer manufacturer with decades of expertise, GNEE (Anyang Jinnaiyuan Steel/GNEE Group) specializes in providing high-performance electrical solutions. Our flagship 2500kVA dry type transformer is engineered to meet the rigorous demands of large-scale power distribution systems, ensuring maximum uptime while significantly reducing energy waste and operational overhead.
When it comes to high-voltage equipment, the manufacturer's credibility is paramount. GNEE is a premier power transformer factory and global supplier, operating from our state-of-the-art production facility in China. We integrate R&D, design, manufacturing, and international logistics to deliver seamless energy solutions.
Our 2500kVA dry type transformer (SCB series) is manufactured using high-grade cold-rolled grain-oriented silicon steel and high-purity oxygen-free copper. By utilizing vacuum pressure casting with epoxy resin, we ensure that every unit meets international standards such as IEC 60076 and CE certifications. Whether you are upgrading an existing grid or building a new data center, GNEE provides the technical expertise and manufacturing scale to support your project’s success.
The core value proposition of the 2500kVA dry type transformer lies in its ability to minimize "No-Load Loss" and "Load Loss." In traditional distribution systems, energy dissipated as heat represents a significant financial drain. GNEE’s advanced core stacking technology and optimized coil design ensure that our transformers operate at peak efficiency even under fluctuating loads.
Reduced Heat Dissipation: By utilizing high-quality Class F or Class H insulation materials, our transformers maintain lower operating temperatures, which extends the lifespan of the insulation system.
Lower Utility Bills: For industrial plants and commercial complexes, the "Low Loss" feature translates directly into thousands of dollars saved annually in electricity costs.
Eco-Friendly Operation: Lower energy consumption means a smaller carbon footprint, helping your facility comply with modern ESG (Environmental, Social, and Governance) requirements.
By choosing our 2500kVA dry type transformer, enterprises can achieve a rapid Return on Investment (ROI) through decreased maintenance and improved power factor performance.
.png)
Managing a 2500kVA load requires a transformer that is both physically robust and electrically stable. GNEE’s 2500kVA dry type transformer is designed with high mechanical strength to withstand short-circuit stresses. The epoxy resin cast coils are moisture-proof, dust-proof, and flame-retardant, making them ideal for indoor environments where oil-filled transformers pose a fire risk.
Partial Discharge Control: Our vacuum casting process ensures partial discharge is kept below 10pC, significantly reducing the risk of internal insulation failure.
Superior Cooling Systems: Equipped with low-noise cross-flow fans, our 2500kVA dry type transformer can handle temporary overloads of up to 40-50% under forced air cooling (AF).
Smart Monitoring: Every unit can be equipped with a digital temperature control system, allowing real-time monitoring and remote alarms to prevent overheating.
.png)
Cost reduction in power systems is not just about the initial purchase price; it is about the Total Cost of Ownership (TCO). The GNEE 2500kVA dry type transformer empowers businesses to cut costs in three distinct ways:
Zero Maintenance: Unlike oil-immersed units, dry-type transformers require no oil testing, filtering, or seal replacements. A simple periodic cleaning of the dust is all that’s needed.
Space-Saving Footprint: Our compact design allows the 2500kVA dry type transformer to be installed closer to the load center, reducing the length of expensive low-voltage cables and minimizing line losses.
Enhanced Safety: Because it is self-extinguishing and fire-resistant, there is no need for expensive fire-fighting walls or oil-collection sumps, reducing overall civil engineering costs.
.png)
To help your engineering team make an informed decision, the following table outlines the standard specifications for our high-capacity units. Note: Custom voltages (e.g., 6.6kV, 11kV, 22kV, 33kV) are available upon request.
| Parameter | Specification Details |
| Rated Capacity | 2500 kVA |
| Transformer Type | SCB Series (Cast Resin Dry Type) |
| Primary Voltage | 10kV / 11kV / 20kV / 33kV |
| Secondary Voltage | 0.4kV / 415V / 440V |
| Phase / Frequency | 3-Phase / 50Hz or 60Hz |
| Insulation Class | Class F (155°C) or Class H (180°C) |
| Cooling Method | AN (Natural Air) / AF (Forced Air) |
| Short Circuit Impedance | 6% / 8% |
| Vector Group | Dyn11 / Yyn0 |
| Enclosure Rating | IP00 / IP20 / IP23 (Customizable) |
At GNEE, we understand that a transformer is a critical asset. Our logistics team ensures that every 2500kVA dry type transformer is packed in seaworthy, reinforced wooden crates with internal shock absorption and moisture barriers. We have successfully exported to over 70 countries, including Southeast Asia, the Middle East, Africa, and South America, ensuring on-time delivery to your project site.
.png)
In conclusion, the 2500kVA dry type transformer from GNEE is the ultimate solution for facilities seeking to balance high power capacity with stringent energy-saving goals. By integrating "Low Loss" technology with a maintenance-free design, we provide a product that not only stabilizes your power distribution but also actively contributes to your bottom line.
Are you ready to optimize your power system? As a trusted 2500kVA dry type transformer manufacturer, GNEE is ready to provide you with a detailed technical proposal and a competitive quotation within 24 hours.
