B23R85 Oriented Silicon Steel

Silicon steel containing 1.0 to 4.5% silicon and less than 0.08% carbon is called silicon alloy steel. It has the characteristics of high permeability, low coercivity and high resistance coefficient, thus the hysteresis loss and eddy current loss are small.
Thickness
0.23 - 0.27 mm
Width
900-1200MM
Product Details
Parameter
Advantage
Service
Message
application Details
Introduction
Cold rolled oriented silicon steel, also known as cold rolled transformer steel, is an important silicon and iron alloy used in the transformer (core) manufacturing industry.
Cold-rolled oriented silicon steel has a complex production process and strict manufacturing technology, and is mainly divided into common oriented silicon steel (CGO) and high magnetic induction oriented silicon steel (HiB). Oriented silicon steel was first discovered by N.P. Goss in the United States in 1930.
technical parameter
Technical
B23R85 steel Mechanical Properties:

Grade

tensile strength
L(N/mm2)

Yield Strength
L(N/mm2)

Elongation
L(%)

Hardness
HV1

Bending frequency (times)

Stacking factor(%)

tensile strength
L(N/mm2)

B23P85

0.23

353

326

12

195

19

96.5


B23P85 electromagnetic performance standards:

Grade

Nominal thickness(mm)

Theoretical density(kg/dm3)

Maximum core loss P17/50
(W/kg)

The minimum magnetic induction B8
(T)

B23P85

0.23

7.65

0.85

1.87



B23R85 silicon steel Features:
1 . stable performance: advanced equipment, manufacturing technology and strict management to ensure the stability of the magnetic and mechanical properties.
2 . excellent processing performance: high dimensional accuracy and a smooth surface for easy cutting and punching, slitting steel for high-speed blanking.
3 . excellent coating properties:. BS series of electrical steel insulation coating has excellent insulating properties, adhesion, punching, heat resistance and weldability, with anti-corrosion (oil and chemicals) role.
4 . high dimensional accuracy: Baosteel advanced equipment and manufacturing technology to ensure the BS series has excellent flatness, smooth surface, uniform thickness, with a small difference plate, lamination factor.

B23R85 silicon steel application :
B23R85 steel mainly used in automotive, excavators, bulldozers, Various types of cranes etc.
